Viking guard Panel system

The importance of the Viking Basic Fencing System has grown over the years in line with the increase in the number of break-ins. Viking Guard Panels are intended for those of you who’d like a bit more than wire mesh fence.

Det är ett stängselsystem med högre säkerhet för varierande användningsområden. Viking Guard Paneler lämpar sig bra genom sitt stolpsystem som fungerar utmärkt för montering i ojämna terrängförhållanden.

  • specification
  • Heights & colours
  • Protection Grade 3
  • Media

The importance of the Viking Basic Fencing System has grown over the years in line with the increase in the number of break-ins. Viking Guard Panels are intended for those of you who'd like a bit more than wire mesh fence. Viking Guard Panels are the strongest of the three types of Demex panels: Viking Guard, Viking Safe, and Viking Basic. It is a fencing system with a higher level of security for varying areas of application. The post system that is extremely easy to install in uneven terrain makes the Viking Guard Panels well-suited to a number of applications. Viking Guard is a fencing system that is joined continuously or at the posts. Viking Guard is suitable for installations with high requirements for security and design, which is why it is a popular choice for industrial and public facilities. Viking Guard is delivered in practically all heights. The system consists of spot-welded net mats, posts, and connecting parts, and can be completed with gate systems with the same net filling.

Fields of application

Parks, public institutions, airports and military facilities, schools, industrial areas, as well as playground and sports facilities.

Strong, secure and aesthetically pleasing

Viking Guard is a fencing system that keeps its shape and gives a professional impression. The vertically and horizontally running grating bars are spot-welded to each other in cross bonds.

Viking Guard Panels

  • Vertical wire: ø 6 mm
  • Horizontal wire: ø 8 mm (double)
  • Mesh size: 50/200 or 100/200mm
  • Panel length: 2,510mm
  • Panel height: 630 to 2,430 mm (additional heights on request)

Viking Guard Fencing Posts

  • Viking Speed posts
  • Viking Alfa posts
  • Viking Beta posts

Keeps its shape and is easy to install

Viking Guard has strong wires which are bent and welded to each other in cross bonds that help the fencing preserve its shape. This results in a user-friendly setup.

Long service life

Panels and posts are GALV-FE hot-dip galvanised as desired according to DIN EN ISO 1461 – this guarantees longer service life – or subsequently get a high-grade Z-LACK powder coating. Mechanical pre-treatment is conducted in connection with galvanising to produce an optimal surface. Priming with epoxy powder guarantees better adhesion and optimum service life of the coating. Z-LACK powder coating with polyester gives optimum rounding to the weather protection.

Viking Guard is available in all colours (always hot-dip galvanised as pre-treatment). The most common of these are:

  • Hot-dipgalvanized (FZV)
  • Dark Green (MG)
  • Olive Green (OG)
  • Black (SV)

Portugal guard has Demex Protection Class 3 and is used in areas where demarcation is important and where there is a higher requirement against burglary and theft.



Protection Grades

Demex develops, produces and maintains perimeter protection solutions and security products of the highest quality. Our tailored comprehensive solutions offer optimum security according to our tried and tested perimeter protection philosophy.

Protection Class 1

Demex Protection Class 1 is used in areas where burglary does not pose a particular risk, but fences and gates are mainly used as boundary demarcation, to show where the property begins and ends. Area protection systems will have a low deterrent effect against possible burglary or unauthorized access.

Protection Class 2

Demex Protection Class 2 is used in areas where delimitation is important and where there is a higher requirement against burglary and theft. It is also used in areas where access to the protected areas can lead to personal injury or death.

Protection Class 3

Demex Protection Class 3 is used when burglary and theft become a serious problem. Access, control of people, vehicles and goods are controlled by automated access control systems. The system is designed to protect the area by deterring, delaying and detecting any burglary attempts and where access to protected areas can lead to injury or death.

Protection Class 4

Demex Protection Class 4 is used when burglary and theft become a critical problem and the protection of the content is very important. Accessibility for authorized persons, vehicles and goods is controlled by automated access control systems. The system is designed to protect the area by deterring, delaying and detecting and taking action against possible burglary attempts and where access to protected areas can lead to injury or death.

Protection Class 5

Demex Protection Class 5 provides the highest level of security in areas where potential burglary poses a serious risk, and is designed to provide complete peace of mind even if there is a potential risk from the outside and inside of the property. The system is designed with an access control system that is used to control access for people, vehicles and goods in and out of the area. It will use all five aspects of Demex’s proven area protection philosophy: deter, delay, detect, take action and control access to protected property with maximum effect. The system will be designed after consultation with the police, insurance companies and professional security companies to provide an area protection that meets the requirements for each individual location.
